Ivory Shaker (F6)
Wall: 30" 36" 39"
Oak Shaker (F5)
Wall: 30" 39"
Shaker Series F5
Available in 30" 39" Height
Oak Shaker pairs the classic five-piece Shaker door with a warm natural oak finish that shows real wood grain. Available in 30" and 39" wall cabinet heights. It shares the same door style as White (F1), Grey (F2), Navy (F3), and Ivory (F6); the same oak finish is also available in the Elegant Series (E5). A strong choice for dealers serving the growing demand for natural wood kitchens.
SPECIFICATIONS
| No. | Part Name | Specification |
|---|---|---|
| 1 | Drawer Front | ¾" thick solid birch wood for the frame and MDF Center Panel for all painted cabinets. |
| 2 | Door | ¾" thick solid birch wood for the frame and MDF Center Panel for all painted cabinets. |
| 3 | Interior Drawer | ⅝" thick solid birch wood for the dovetailed drawer side panel, ⅜" thick plywood for the drawer box bottom panel |
| 4 | Shelf | ¾" thick Plywood shelf in full depth with front and back finished edge |
| 5 | Side Panel | ½" matching finish Plywood side panels, UV-coated |
| 6 | Toe Kick | ½" thick and 4½" height matching finished plywood toe kick attached to the cabinet, UV-coated |
| 7 | Back Panel | ½" matching finish Plywood back panels, UV-coated |
| 8 | Bracket | Metal bracket reinforcement for base cabinet |
| 9 | Drawer Glide | DTC brand with soft close and full extension under-mount |
| 10 | Cabinet Frame | ¾" thick and 1½" wide solid birch wood face frame with double-dowel joint |
| 11 | Top Panel | ½" thick plywood with UV-coated |
| 12 | Hinge | DTC brand soft close six ways adjustable |
Cabinets have finished UV-coated interiors with matching door colors. Drawer boxes have a natural wood finish.
MORE COLORS IN SHAKER SERIES
OAK IN OTHER SERIES
